Helical Solutions

3/4" 5-Flute Solid Carbide Corner Radius End Mill, Nplus - Helical Solutions 84282

MFR# 84282Series HVAL-C-5

$447.73List $522.72 Save 14%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/4

Flutes5

MaterialSolid Carbide

CoatingNplus

Description

The Helical Solutions 84282 is a 3/4 5-flute Solid Carbide corner radius end mill with a Nplus finish for longer tool life. Suited for non-ferrous metal. 1-5/8 length of cut, 4 overall length. Series HVAL-C-5.

Specifications

CentercuttingYes

ChipbreakerYes

Coating finishNplus

Coolant throughNo

Corner radius0.0600

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeHelical

For use withHigh Precision Toolholder

Length of cut in1-5/8

Length typeRegular

Material applicationWrought Aluminum; Cast Aluminum; Graphite; Non-Ferrous Metal

Material removal typeRoughing

Mill diameter in3/4

Mill diameter tolerance-0.0020 to 0.0000 in

Number of flutes5

Overall length in4

Overall length tolerance-0.0620 to 0.0620 in

PitchVariable

Primary workpiece materialNon-Ferrous Metal

Shank diameter in3/4

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0003

Variable helixNo

Variable indexYes
