1/2" 6-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 84321

Helical Solutions

1/2" 6-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 84321

MFR# 84321Series HEVC-6

$297.45List $347.27 Save 14%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes6
MaterialSolid Carbide
CoatingTplus

Description

The Helical Solutions 84321 is a 1/2 6-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, high temperature alloy, hard material. 1-1/4 length of cut, 3 overall length. Series HEVC-6.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTplus
Coolant throughYes
Corner radius0.0300
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut in1-1/4
Length typeRegular
Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel
Material removal typeRoughing & Finishing
Mill diameter in1/2
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes6
Overall length in3
Overall length tolerance-0.0620/0.0620 in
PitchVariable
Primary workpiece materialStainless Steel; High Temperature Alloy; Hard Material
Shank diameter in1/2
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexYes
