5/8" 2-Flute Solid Carbide Square End Mill, AlTiN - Hertel 750396

Hertel

5/8" 2-Flute Solid Carbide Square End Mill, AlTiN - Hertel 750396

MFR# 750396

$96.68List $124.00 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter5/8
Flutes2
MaterialSolid Carbide
CoatingAlTiN

Description

The Hertel 750396 is a 5/8 2-flute Solid Carbide (Micrograin) square end mill. 3/4 length of cut, 3 overall length.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishAlTiN
Cutting directionRight Hand
End mill materialSolid Carbide
Helix angle30
Length of cut in3/4
Length of cut range0.7000 - 0.8000
Material gradeMicrograin
Mill diameter in5/8
Number of flutes2
Overall length in3
Shank diameter in5/8
Variable helixNo
Variable indexNo
