0.8543" IC Solid Carbide Insert, Grade TI25 - HORN 613030000TI25

HORN

0.8543" IC Solid Carbide Insert, Grade TI25 - HORN 613030000TI25

MFR# 613030000TI25Series 613

$83.47List $89.60 Save 6%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Sold in multiples of 10 — minimum order 10

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
GradeTI25
MaterialSolid Carbide

Description

The HORN 613030000TI25 is a solid carbide indexable insert, grade TI25. Suited for hard material, cast iron, stainless steel, non-ferrous metal, steel, superalloys & titanium.

Specifications

Corner radius0.0080
Inscribed circle0.8543
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert size03
Insert size code0300
Insert style613
Manufacturers catalog number613030000TI25
Manufacturer gradeTI25
Material applicationHard Material; Cast Iron; Stainless Steel; Non-Ferrous Metal; Steel; Superalloys & Titanium
Maximum depth of cut0.1771
Primary workpiece materialHard Material; Cast Iron; Stainless Steel; Non-Ferrous Metal; Steel; Superalloys & Titanium
RakePositive
Single or double sided insertSingle
Thickness0.2240
Width0.8543
