Ingersoll Cutting Tools
SHLT090408N-FS Carbide Insert, Grade IN1030, TiCN - Ingersoll Cutting Tools 5100996
MFR# 5100996ISO/ANSI# SHLT090408N-FSSeries SHLT-N-FS
$19.38List $24.40
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 10 — minimum order 10
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeIN1030
MaterialCarbide
CoatingTiCN
Description
The Ingersoll Cutting Tools 5100996 is a SHLT090408N-FS carbide indexable insert, grade IN1030, TiCN coated. Suited for steel, stainless steel, super-alloys & titanium.
Specifications
Ansi codeSHLT090408N-FS
ChipbreakerFS
Coating finishTiCN
Coating processPVD
Compatible drill style15S; DHU
Corner radius0.0300
Cutting directionNeutral
Included angle degree90
Inscribed circle0.3720
Insert materialCarbide
Insert size090408
Insert size code09
Insert styleSHLT
Iso codeSHLT090408N-FS
Length0.3720
Manufacturer gradeIN1030
Material gradeC1; C2; C6
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Super-Alloys & Titanium
RakePositive
ShapeSquare
Thickness0.1810
Width0.3720
