RJLT2007MOTN IN2540 Solid Carbide Insert, Grade IN2540, TiAlN - Ingersoll Cutting Tools 5614619

Ingersoll Cutting Tools

RJLT2007MOTN IN2540 Solid Carbide Insert, Grade IN2540, TiAlN - Ingersoll Cutting Tools 5614619

MFR# 5614619ISO/ANSI# RJLT2007MOTN IN2540Series RJLT

$32.42List $40.80 Save 20%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Sold in multiples of 10 — minimum order 10

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeRound
GradeIN2540
MaterialSolid Carbide
CoatingTiAlN

Description

The Ingersoll Cutting Tools 5614619 is a RJLT2007MOTN IN2540 solid carbide indexable insert, grade IN2540, TiAlN coated. Suited for steel, cast iron.

Specifications

Ansi codeRJLT2007MOTN IN2540
Chip breakerNone
Coating finishTiAlN
Coating processPVD
Corner radius0.3937
Cutter series compatibility1A7M
Cutting edge styleChamfered
Included angle degree360
Inscribed circle0.7874
Inscribed circle range0.7000 to 1.0000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRound
Insert size20
Insert size code2007
Insert styleRJLT
Iso codeRJLT2007MOTN IN2540
Length0.7874
Length of cut (mm)10.0000
Length range0.7000 to 0.9000
Manufacturers catalog number5614619
Manufacturer gradeIN2540
Material applicationSteel; Cast Iron
Material gradeFine Grain; Medium Grain
Maximum depth of cut (mm)10.00
Multi use toolNo
Number of cutting edges4
Primary workpiece materialSteel; Cast Iron
RakePositive
Single or double sided insertSingle
StandardsANSI; ISO
Thickness0.2756
Thickness range0.2500 to 0.3500
Width0.7874
