THLS060408FR IN2505 Solid Carbide Insert, Grade IN2505, TiAlN - Ingersoll Cutting Tools 5615061
MFR# 5615061ISO/ANSI# THLS060408FR IN2505Series THLS
$17.26List $22.10
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeTriangle
GradeIN2505
MaterialSolid Carbide
CoatingTiAlN
Description
The Ingersoll Cutting Tools 5615061 is a THLS060408FR IN2505 solid carbide indexable insert, grade IN2505, TiAlN coated. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material.
Specifications
Ansi codeTHLS060408FR IN2505
Chip breakerHR
Coating finishTiAlN
Coating processPVD
Corner radius in1/32
Cutter series compatibility1K_1D; 1KJ1D; 1KV1D; KJ5D
Cutting edge styleCorner Rounded
Included angle degree60
Inscribed circle0.2720
Inscribed circle range0.2000 to 0.3000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeTriangle
Insert size06
Insert size code060408
Insert styleTHLS
Iso codeTHLS060408FR IN2505
Length of cut (mm)6.8600
Manufacturers catalog number5615061
Manufacturer gradeIN2505
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Material gradeMicrograin
Maximum depth of cut0.2700
Multi use toolNo
Number of cutting edges3
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
RakePositive
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in5/32
Thickness range0.1500 to 0.1750
Width0.2720
