SDMT1204PDSR-MJ Solid Carbide Insert, Grade IN1030, TiCN - Ingersoll Cutting Tools 5802603

MFR# 5802603ISO/ANSI# SDMT1204PDSR-MJSeries APEB

$24.16List $30.40 Save 20%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Sold in multiples of 10 — minimum order 10

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/8
ShapeParallelogram
GradeIN1030
MaterialSolid Carbide
CoatingTiCN

Description

The Ingersoll Cutting Tools 5802603 is a SDMT1204PDSR-MJ solid carbide indexable insert, grade IN1030, TiCN coated. Suited for steel, stainless steel, superalloys & titanium.

Specifications

Ansi codeAPEB53R05 IN1030
Chip breakerCommon
Coating finishTiCN
Coating processPVD
Corner radius in1/4
Cutter series compatibility12J1B; 12J4B; 22J3B; 22J5B; 23J6G; 2J1B
Cutting edge effective length0.6000
Cutting edge styleSharp
Included angle degree85
Inscribed circle in3/8
Inscribed circle range0.3500 to 0.4000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeParallelogram
Insert size53
Insert size code53
Insert styleAPEB
Iso codeSDMT1204PDSR-MJ
Length0.6360
Length range0.6000 to 0.6500
Manufacturers catalog number5802603
Manufacturer gradeIN1030
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Material gradeCoarse Grain
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Relief angle11.00
Single or double sided insertSingle
StandardsANSI; ISO
Thickness0.2050
Thickness range0.2000 to 0.2200
Width in3/8
