Ingersoll Cutting Tools
CNMX160712HB TT8115B Carbide Insert, Grade TT8115B, Al2O3 - Ingersoll Cutting Tools 6213104
MFR# 6213104ISO/ANSI# CNMX160712HB TT8115BSeries CNMX
$30.43List $38.35
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeDiamond
GradeTT8115B
MaterialCarbide
CoatingAl2O3
Description
The Ingersoll Cutting Tools 6213104 is a CNMX160712HB TT8115B carbide indexable insert, grade TT8115B, Al2O3 coated. Suited for steel.
Specifications
Chip breakerHB
Clearance codeN
Coating finishAl2O3
Coating processCVD
Corner radius0.0470
Included angle80
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp
Insert length0.6350
Insert materialCarbide
Insert shapeDiamond
Insert size code553
Insert styleCNMX
Insert thickness0.2720
Iso codeCNMX160712HB TT8115B
Manufacturer gradeTT8115B
Maximum depth of cut0.3150
Number of cutting edges4
Primary workpiece materialSteel
RakeNegative
Relief angle0
Tolerance codeM
Width in1
Wiper edgeNo
