Iscar
Indexable Cut-Off - Iscar 2300519
MFR# 2300519Cat# SGFH 26-5Series Self Grip
$166.46List $168.90
Save 1%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 2300519 indexable cut-off. Series Self Grip.
Specifications
Blade height1.0236
Blade overall length4.3307
Blade styleSGFH
Blade width0.1575
Complete insert compatibilityGF.. 4.8; GF.. 5..
Cutting directionRight Hand
Cutting height0.8425
Cutting tool applicationGrooving; Parting; Turning
End typeSingle
HandRight Hand
Insert holding methodSelf Grip
Insert width0.1890
Insert width (mm)4.80
Manufacturers catalog numberSGFH 26-5
Maximum insert width0.1787
Maximum workpiece diameter3.1500
Minimum insert width0.1780
StandardsISO 13399
