Iscar
Indexable Cut-Off - Iscar 2300616
MFR# 2300616Series Self Grip
$163.57List $168.90
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 2300616 indexable cut-off. Series Self Grip.
Specifications
Blade height1.0236
Blade overall length4.3307
Blade styleSGIH
Blade width0.1575
Complete insert compatibilityGT.. 4.8; GT.. 5..
Complete tool block toolholder style compatibilitySGTBR 16-5; SGTBR 19-5; SGTBR 25-6
Cutting directionRight Hand
Cutting height0.8425
Cutting tool applicationCut-Off
End typeDouble
HandRight Hand
Insert holding methodSelf Grip
Insert width0.1870
Maximum insert width0.2008
Maximum workpiece diameter3.1500
Minimum insert width0.1890
Tool block styleSGTBR
