Iscar
Indexable Grooving - Iscar 2301289
MFR# 2301289Series Do Grip
$204.15List $210.80
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 2301289 indexable grooving. Series Do Grip.
Specifications
Compatible insert size codeDGN-LF/LFT; DGN-MF; DGN-P; DGN-UT/UA; DGN-WP; DGN-Z; DGN/DGNC/DGNM-C; DGN/DGNM-J/JS/JT; DGR-P; DGR-WP; DGR-Z/ZS; DGR/L-C DGRC/LC-C; DGR/L-J/JS
Coolant throughNo
Cutting tool applicationCut-Off; Grooving
Full radius insertNo
Hand of holderRight Hand
Head length1.2200
Insert compatibilityDG. 4..; GRIP 4..
Insert holding methodClamp
Maximum groove width0.1570
Minimum groove width0.1570
Msc manufacturer numberDGTR 25.4-4
Overall length6.0000
Shank height1.0000
Shank length4.7800
Shank width diameter in1
StandardsISO 13399
Toolholder styleDGT
