Iscar
Indexable Cut-Off - Iscar 2394956
MFR# 2394956Cat# DGAD 3NSeries Do-Grip
$140.22List $144.80
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 2394956 indexable cut-off. Series Do-Grip.
Specifications
Blade height1.1811
Blade overall length1.6339
Blade styleDGAD
Blade width0.1575
Cutting directionNeutral
Cutting height0.9449
Cutting tool applicationGrooving; Parting; Turning
End typeDouble
Insert holding methodSelf Grip
Insert styleDGN R/L..; DGN..; GRIP..; HGN..; HGR/L..
Manufacturers catalog numberDGAD 3N
Maximum insert width0.1252
Maximum workpiece diameter1.2600
Minimum insert width0.1181
StandardsISO 13399
