Indexable End Mills - Iscar 3100503
MFR# 3100503Cat# E45X D .25-W .50-06Series Heliquad
$246.94List $255.00
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 3100503 indexable end mills. Series Heliquad.
Specifications
Functional length0.8000
Head length0.8000
Insert holding methodScrew
Manufacturers catalog numberE45X D .25-W .50-06
Maximum body diameter0.5000
Maximum cutting diameter0.5700
Maximum depth of cut0.1500
Minimum cutting diameter in1/4
Overall length2.7500
Shank diameter in1/2
Shank typeWeldon Flat
StandardsISO 13399
Toolholder styleE45; E45X
Tool applicationMilling
