Iscar
Indexable End Mills - Iscar 3100504
MFR# 3100504Cat# E45X D .31-W .62-06Series Heliquad
$246.94List $255.00
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes1
Description
The Iscar 3100504 indexable end mills. Series Heliquad.
Specifications
Compatible insert size codeSDMT-AD-N
Coolant throughNo
Functional length1.0000
Head length1.0000
Included angle degree45
Insert holding methodScrew Clamping
Insert styleSDMT..AD.N
Manufacturers catalog numberE45X D .31-W .62-06
Maximum body diameter0.6250
Maximum cutting diameter0.6300
Maximum depth of cut0.1500
Maximum rpm7000
Minimum cutting diameter0.3120
Number of cutter inserts1
Number of flutes1
Number of inserts included in order1
Overall length3.2500
Shank diameter in5/8
Shank length2.2500
Shank typeWeldon Flat
StandardsISO 13399
Toolholder styleE45; E45X
Tool applicationMilling
