Iscar
Indexable End Mills - Iscar 3110505
MFR# 3110505Series Heliquad
$246.94List $255.00
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes1
Description
The Iscar 3110505 indexable end mills. Series Heliquad.
Specifications
Compatible insert size codeX/Q/SOMT 06
Coolant throughNo
Functional length (mm)25.00
Head length (mm)25.00
Insert holding methodScrew
Insert styleX/Q/SOMT 06
Maximum body diameter (mm)12.00
Maximum cutting diameter (mm)14.10
Maximum depth of cut (mm)4.00
Minimum cutting diameter (mm)6.00
Number of cutter inserts1
Number of flutes1
Overall length (mm)80.00
Shank diameter (mm)12.00
Shank typeCylindrical
StandardsISO 13399
Toolholder styleE45X
Tool applicationMilling
