Iscar
Indexable Milling Cutters - Iscar 3110788
MFR# 3110788Series MillShred
$997.46List $1,030.00
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes8
Description
The Iscar 3110788 indexable milling cutters. Series MillShred.
Specifications
Arbor hole diameter1.0000
Compatible insert size codeP290 AC T1806
Complete insert compatibilityP290 ACCT 1806PDR-HL; P290 ACKT 1806PDR-FW; P290 ACKT 1806PDR-FWE; P290 ACKT 1806PDR-FWR
Coolant throughYes
Counterbore diameter0.7800
Cutter styleP290 FPW
Cutting directionRight Hand
Hub diameter2.1700
Insert holding methodClamp; Screw
Keyway width0.3750
Lead angle0
Maximum cutting diameter in3
Maximum depth of cut0.7080
Maximum ramping angle0.50
Number of cutter inserts8
Number of flutes8
Overall height1.7500
StandardsISO
