Iscar
Carbide Insert, Grade IC908, TiAlN - Iscar 3336736
MFR# 3336736Series MM EC-Z4-1.5xD
$327.24List $412.40
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
GradeIC908
CoatingTiAlN
Description
The Iscar 3336736 is a carbide indexable insert, grade IC908, TiAlN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.
Specifications
Chamfer angle0degree
ChipbreakerNone
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Corner radius0.0310
Cutting diameter (mm)19.05
Cutting width0.7500in
Functional length1.6140
Helix angle46
Included angle degree90
Insert handRight Hand
Insert size750H112R031
Lead angle90
Length of cut in1-1/8in
Manufacturers catalog number3336736
Manufacturer gradeIC908
Material gradeSub Micrograin
Maximum depth of cut1.125
Milling tip full descriptionMM EC750H112R031CF-4T12
Milling tip styleMM EC
Milling tip typeCorner Radius
Number of flutes4
Overall length1.6140in
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
StandardsANSI
Tool materialCarbide
