Iscar
3/4" 4-Flute Solid Carbide Square End Mill, AlTiCrSiN - Iscar 3398349
MFR# 3398349Series ECI-4-VF
$284.13List $340.70
Save 16%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter3/4
Flutes4
MaterialSolid Carbide
CoatingAlTiCrSiN
Description
The Iscar 3398349 is a 3/4 4-flute Solid Carbide (Submicron) square end mill with a AlTiCrSiN finish for longer tool life. Suited for hardened materials, cast iron, stainless steel, steel, high-temp alloy. 3 length of cut, 6 overall length. Series ECI-4-VF.
Specifications
CentercuttingNo
ChipbreakerNo
Coating finishAlTiCrSiN
Coating finish familyAlTiCrSiN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle38
Length of cut in3
Material gradeSubmicron
Mill diameter in3/4
Number of flutes4
Overall length in6
Primary workpiece materialHardened Materials; Cast Iron; Stainless Steel; Steel; High-Temp Alloy
Shank diameter in3/4
Single or double endSingle
System of measurementFractional Inch
Variable helixNo
Variable indexYes
