Iscar
1" 5-Flute Solid Carbide Corner Radius End Mill, AlTiCrSiN - Iscar 3398380
MFR# 3398380Cat# ECI-5 1.-2.C.015VF4.5Series ECI-5-VF
$563.81List $723.11
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1
Flutes5
MaterialSolid Carbide
CoatingAlTiCrSiN
Description
The Iscar 3398380 is a 1 5-flute Solid Carbide (Submicron) corner radius end mill with a AlTiCrSiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 2 length of cut, 4-1/2 overall length. Series ECI-5-VF.
Specifications
CentercuttingNo
ChipbreakerNo
Coating finishAlTiCrSiN
Coolant throughNo
Corner radius0.0150
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholder
Length of cut in2
Length typeShort
Manufacturers catalog numberECI-5 1.-2.C.015VF4.5
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Material gradeSubmicron
Material removal typeRoughing & Finishing
Mill diameter in1
Number of flutes5
Overall length in4-1/2
PitchNormal
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length in2
Shank diameter in1
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexYes
