Iscar
3/8" 5-Flute Solid Carbide Corner Radius End Mill, AlTiCrSiN - Iscar 3398396
MFR# 3398396Cat# ECI-5 .375-1.C.03VF2.5Series ECI-5-VF
$79.95List $94.20
Save 15%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter3/8
Flutes5
MaterialSolid Carbide
CoatingAlTiCrSiN
Description
The Iscar 3398396 is a 3/8 5-flute Solid Carbide (Submicron) corner radius end mill with a AlTiCrSiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 1 length of cut, 2-1/2 overall length. Series ECI-5-VF.
Specifications
CentercuttingNo
ChipbreakerNo
Coating finishAlTiCrSiN
Coolant throughNo
Corner radius0.0300
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholder
Length of cut in1
Length typeMedium
Manufacturers catalog numberECI-5 .375-1.C.03VF2.5
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Material gradeSubmicron
Material removal typeRoughing & Finishing
Mill diameter in3/8
Number of flutes5
Overall length in2-1/2
PitchNormal
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length in1
Shank diameter in3/8
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexYes
