1/2" 5-Flute Solid Carbide Square End Mill, TiAlCN - Iscar 3398536

Iscar

1/2" 5-Flute Solid Carbide Square End Mill, TiAlCN - Iscar 3398536

MFR# 3398536

$130.01List $155.90 Save 16%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes5
MaterialSolid Carbide
CoatingTiAlCN

Description

The Iscar 3398536 is a 1/2 5-flute Solid Carbide (Submicron) square end mill with a TiAlCN finish for longer tool life. 2-1/2 length of cut, 5 overall length.

Specifications

CentercuttingYes
Coating finishTiAlCN
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle38
Length of cut in2-1/2
Material gradeSubmicron
Mill diameter in1/2
Number of flutes5
Overall length in5
Shank diameter in1/2
Variable helixNo
Variable indexYes
Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.
