Iscar

1/2" 5-Flute Solid Carbide Corner Radius End Mill, AlTiCrSiN - Iscar 3398576

MFR# 3398576Cat# ECI-5 .5-.88/2.13C.03VF4.Series ECI-5-VF

$149.36List $179.10 Save 16%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes5

MaterialSolid Carbide

CoatingAlTiCrSiN

Description

The Iscar 3398576 is a 1/2 5-flute Solid Carbide (Submicron) corner radius end mill with a AlTiCrSiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 7/8 length of cut, 4 overall length. Series ECI-5-VF.

Specifications

CentercuttingNo

ChipbreakerNo

Coating finishAlTiCrSiN

Coolant throughNo

Corner radius0.0300

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

For use withToolholder

Length of cut in7/8

Length typeShort

Manufacturers catalog numberECI-5 .5-.88/2.13C.03VF4.

Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material

Material gradeSubmicron

Material removal typeRoughing & Finishing

Mill diameter in1/2

Number of flutes5

Overall length in4

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material

Reach length in2-1/8

Shank diameter in1/2

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Variable helixNo

Variable indexYes
