1/2in" 5-Flute Solid Carbide Corner Radius End Mill, AlTiCrSiN - Iscar 3398577

Iscar

1/2in" 5-Flute Solid Carbide Corner Radius End Mill, AlTiCrSiN - Iscar 3398577

MFR# 3398577Cat# ECI-5 .5-.88/2.13C.03VF5.Series ECI-5-VF

$171.87List $206.10 Save 16%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2in
Flutes5
MaterialSolid Carbide
CoatingAlTiCrSiN

Description

The Iscar 3398577 is a 1/2in 5-flute Solid Carbide (Submicron) corner radius end mill with a AlTiCrSiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 7/8in length of cut, 5in overall length. Series ECI-5-VF.

Specifications

CentercuttingNo
ChipbreakerNo
Coating finishAlTiCrSiN
Coolant throughNo
Corner radius0.0300
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
For use withToolholders
Length of cut in7/8in
Length typeShort
Manufacturers catalog numberECI-5 .5-.88/2.13C.03VF5.
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Material gradeSubmicron
Material removal typeRoughing & Finishing
Mill diameter in1/2in
Number of flutes5
Overall length in5in
PitchNormal
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length in3-1/8
Shank diameter in1/2in
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexYes
