Iscar
Indexable Turning & Profiling - Iscar 3603419
MFR# 3603419Series DoveIQTurn
$170.50List $173.00
Save 1%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 3603419 indexable turning & profiling. Series DoveIQTurn.
Specifications
Back of bar to cutting edge1.6000
Compatible insert size codeCOMG643-R3P-IQ
Coolant throughNo
Cutting directionLeft Hand
Cutting tool applicationTurning
Hand of holderLeft Hand
Head length1.5000
Insert compatibilityCOMG 543-R3P-IQ; COMG 643-R3P-IQ; COMG 644-R3P-IQ; COMG 646-R3P-IQ
Insert holding methodLever
Insert inscribed circle0.7500
Multi use toolNo
Overall length6.0000
RakeNeutral
Rake angle-6
Shank height1.2500
Shank width1.2500
StandardsISO 13399
Toolholder stylePCLO
