Iscar
BT30 Collet Chuck - Iscar 4510001
MFR# 4510001
$216.06List $266.50
Save 18%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Iscar 4510001 is a BT30 Collet Chuck.
Specifications
Balanced to rpm12000
Collet seriesER16
Collet systemER
Coolant typeThrough-Spindle & DIN Flange
Maximum collet capacity0.3937
Minimum collet capacity0.0197
Nose diameter1.1024
Projection2.7600
Shank typeTaper
Taper sizeBT30
Through coolantYes
Tir0.000100
