Iscar
SNMG432 Solid Carbide Insert, Grade IC806, TiAlN - Iscar 5510106
MFR# 5510106ISO/ANSI# SNMG432Series Isoturn
$15.67List $20.10
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeSquare
GradeIC806
MaterialSolid Carbide
CoatingTiAlN
Description
The Iscar 5510106 is a SNMG432 solid carbide indexable insert, grade IC806, TiAlN coated. Suited for s.
Specifications
Chip breakerEM-R
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius in1/32
Hole diameter0.2030
Included angle90.0
Inscribed circle in1/2
Insert holding methodClamp; Pin
Insert materialSolid Carbide
Insert shapeSquare
Insert size code432
Insert styleSNMG
Insert thickness in3/16
Iso codeSNMG432
Manufacturer gradeIC806
Material gradeSubmicron
Maximum depth of cut0.2362
Number of cutting edges4
Primary workpiece materialS
RakePositive
Relief angle0
Secondary workpiece materialM
StandardsISO 13399
Stocking categoryD
Tolerance codeM
Width in1/2
