Iscar
Diamond 1/2" IC Solid Carbide Insert, Grade IC8150, TiCN - Iscar 5550224
MFR# 5550224
$21.99List $28.20
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeDiamond
GradeIC8150
MaterialSolid Carbide
CoatingTiCN
Description
The Iscar 5550224 is a solid carbide indexable insert, grade IC8150, TiCN coated. Suited for p.
Specifications
Chip breakerT
Clearance codeC
Coating finishTiCN
Coating processCVD
Corner radius in1/32
Hole diameter0.2165
Included angle80.0
Inscribed circle in1/2
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeDiamond
Insert size code432
Insert styleCCMT
Insert thickness in3/16
Manufacturer gradeIC8150
Primary workpiece materialP
Relief angle7
Secondary workpiece materialK
Stocking categoryD
Tolerance codeM
