Iscar
CNMG090408-M3P Solid Carbide Insert, Grade IC8150, TiCN - Iscar 5567565
MFR# 5567565ISO/ANSI# CNMG090408-M3PCat# CNMG 090408-M3PSeries Isoturn
$13.64List $17.50
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeDiamond
GradeIC8150
MaterialSolid Carbide
CoatingTiCN
Description
The Iscar 5567565 is a CNMG090408-M3P solid carbide indexable insert, grade IC8150, TiCN coated. Suited for cast iron, steel.
Specifications
Chip breakerM3P
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius in1/32
Included angle80.0
Inscribed circle in3/8
Insert holding methodClamp; Pin
Insert length0.3807
Insert materialSolid Carbide
Insert shapeDiamond
Insert size code332
Insert styleCNMG
Insert thickness in3/16
Iso codeCNMG090408-M3P
Length range0.3000 - 0.4000
Manufacturers catalog numberCNMG 090408-M3P
Manufacturer gradeIC8150
Maximum depth of cut0.1772
Multi use toolNo
Primary workpiece materialCast Iron; Steel
RakePositive
Relief angle0
Single or double endDouble
StandardsISO 13399
Tolerance codeM
