Iscar
CNMG 433-GN Solid Carbide Insert, Grade IC830, TiAlN - Iscar 5568603
MFR# 5568603ISO/ANSI# CNMG 433-GNSeries Isoturn
$16.37List $21.00
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeDiamond
GradeIC830
MaterialSolid Carbide
CoatingTiAlN
Description
The Iscar 5568603 is a CNMG 433-GN solid carbide indexable insert, grade IC830, TiAlN coated. Suited for m, p, s.
Specifications
Chip breakerGN
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius0.0470
Included angle80.0
Inscribed circle0.5000
Insert handRight Hand
Insert length0.5080
Insert materialSolid Carbide
Insert shapeDiamond
Insert size code433
Insert styleCNMG
Insert thickness0.1870
Iso codeCNMG 433-GN
Length range0.5000 - 0.6000
Manufacturers catalog number5568603
Manufacturer gradeIC830
Maximum depth of cut0.1970
Primary workpiece materialM; P; S
Secondary workpiece materialNone
StandardsISO 13399
Tolerance codeM
