Iscar
CNMG 543-M3M Carbide Insert, Grade IC807, TiAlN - Iscar 5569355
MFR# 5569355ISO/ANSI# CNMG 543-M3MSeries Isoturn
$28.39List $36.40
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeDiamond
GradeIC807
MaterialCarbide
CoatingTiAlN
Description
The Iscar 5569355 is a CNMG 543-M3M carbide indexable insert, grade IC807, TiAlN coated.
Specifications
Chip breakerM3M
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius0.0470
Included angle80
Inscribed circle in5/8
Insert handRight Hand
Insert length0.6350
Insert materialCarbide
Insert shapeDiamond
Insert size code543
Insert styleCNMG
Insert thickness in1/4
Iso codeCNMG 543-M3M
Length range0.6000 - 0.6500
Manufacturers catalog number5569355
Manufacturer gradeIC807
Maximum depth of cut0.2760
RakePositive
StandardsISO 13399
Tolerance codeM
