Iscar
ISO 13399 Solid Carbide Insert, Grade IC9150, TiCN - Iscar 5591796
MFR# 5591796ISO/ANSI# ISO 13399Series Isoturn
$21.10List $26.60
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
Sold in multiples of 10 — minimum order 10
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeSquare
GradeIC9150
MaterialSolid Carbide
CoatingTiCN
Description
The Iscar 5591796 is a ISO 13399 solid carbide indexable insert, grade IC9150, TiCN coated. Suited for p.
Specifications
Chip breakerSM
Clearance codeC
Coating finishTiCN
Coating processCVD
Corner radius in1/32
Hole diameter0.2165
Included angle90.0
Inscribed circle in1/2
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeSquare
Insert size code432
Insert styleSCMT
Insert thickness in3/16
Iso codeISO 13399
Manufacturer gradeIC9150
Maximum depth of cut0.1575
Primary workpiece materialP
RakePositive
Relief angle7
Secondary workpiece materialK
StandardsISO 13399
Stocking categoryD
Tolerance codeM
Width in1/2
