ISO 13399 Carbide Insert, Grade IC07 - Iscar 5597365

Iscar

ISO 13399 Carbide Insert, Grade IC07 - Iscar 5597365

MFR# 5597365ISO/ANSI# CNGG120408Series Isoturn

$23.39List $30.00 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeC - Diamond (Rhombic) 80-Deg
GradeIC07
MaterialCarbide

Description

The Iscar 5597365 is a ISO 13399 carbide indexable insert, grade IC07.

Specifications

Ansi insert codeCNGG432
Ansi size code432
Chip breakerPP
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating processUncoated
Corner radius0.0315
Grade characteristicsStainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Aluminum & Non-Ferrous (N) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance
Included angle80
Inscribed circle0.5000
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code432
Insert styleCNGG
Iso codeISO 13399
Iso insert codeCNGG120408
Iso size code120408
Manufacturer gradeIC07
Maximum depth of cut0.1570
RakePositive
Side clearanceNegative
StandardsISO 13399
Tolerance codeG
