SEKT 12T3AFTN Solid Carbide Insert, Grade IC328, TiCN - Iscar 5601839

Iscar

SEKT 12T3AFTN Solid Carbide Insert, Grade IC328, TiCN - Iscar 5601839

MFR# 5601839ISO/ANSI# SEKT 12T3AFTNCat# SEKT 12T3AFTN IC328Series ISCARMILL

$19.18List $24.60 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeSquare
GradeIC328
MaterialSolid Carbide
CoatingTiCN

Description

The Iscar 5601839 is a SEKT 12T3AFTN solid carbide indexable insert, grade IC328, TiCN coated. Suited for steel, stainless steel, superalloys & titanium.

Specifications

Ansi codeSEKT 12T3AFTN IC328
Chip breakerTN
Coating finishTiCN
Coating processPVD
Corner radius0.0000
Cutter series compatibilityF45ST
Cutting edge effective length0.5177
Cutting edge styleSharp
Included angle degree90
Inscribed circle0.5180
Inscribed circle range0.5100 to 0.6000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeSquare
Insert size12
Insert size code12T3
Insert styleSEKT
Iso codeSEKT 12T3AFTN
Length0.5177
Length range0.5000 to 0.6000
Manufacturers catalog numberSEKT 12T3AFTN IC328
Manufacturer gradeIC328
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Maximum depth of cut0.2560
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Relief angle20
Single or double sided insertSingle
StandardsANSI; ISO 13399
Thickness0.1460
Thickness range0.1250 to 0.1500
Width0.5180
