QDMT 120516PDTN-M Solid Carbide Insert, Grade IC908, TiAlN - Iscar 5603736

Iscar

QDMT 120516PDTN-M Solid Carbide Insert, Grade IC908, TiAlN - Iscar 5603736

MFR# 5603736ISO/ANSI# QDMT 120516PDTN-MCat# QDMT 120516PDTN-M IC908Series HELIQUAD

$23.27List $29.80 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeSquare
GradeIC908
MaterialSolid Carbide
CoatingTiAlN

Description

The Iscar 5603736 is a QDMT 120516PDTN-M solid carbide indexable insert, grade IC908, TiAlN coated. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material.

Specifications

Ansi codeQDMT 120516PDTN-M IC908
Chip breakerM
Coating finishTiAlN
Coating processPVD
Corner radius0.0630
Cutter series compatibilityFDN; FST; SDN; SSB; SDK; F90SD
Cutting edge effective length0.4370
Cutting edge styleT-Land
Included angle degree90
Inscribed circle in1/2
Inscribed circle range0.5000 to 0.5100
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeSquare
Insert size12
Insert size code120516
Insert styleQDMT
Iso codeQDMT 120516PDTN-M
Length in1/2
Length range0.5000 to 0.6000
Manufacturers catalog numberQDMT 120516PDTN-M IC908
Manufacturer gradeIC908
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Material gradeSubmicron
Maximum depth of cut0.3940
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
RakePositive
Rake angle22
Relief angle15
Single or double sided insertSingle
StandardsANSI; ISO 13399
Thickness0.1970
Thickness range0.1850 to 0.2000
Width in1/2
