HP ADCT 2207PDR Solid Carbide Insert, Grade IC928, TiAlN - Iscar 5604054

Iscar

HP ADCT 2207PDR Solid Carbide Insert, Grade IC928, TiAlN - Iscar 5604054

MFR# 5604054ISO/ANSI# HP ADCT 2207PDRCat# HP ADCT 2207PDR IC928Series HELIPLUS

$40.52List $51.90 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeParallelogram
GradeIC928
MaterialSolid Carbide
CoatingTiAlN

Description

The Iscar 5604054 is a HP ADCT 2207PDR solid carbide indexable insert, grade IC928, TiAlN coated. Suited for steel, stainless steel, superalloys & titanium.

Specifications

Ansi codeHP ADCT 2207PDR IC928
Chip breakerPDR
Coating finishTiAlN
Coating processPVD
Corner radius0.0394
Cutter series compatibilityHM90-15
Cutting edge effective length0.8900
Cutting edge styleHoned
Included angle degree85
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeParallelogram
Insert size22
Insert size code2207
Insert styleADCT
Iso codeHP ADCT 2207PDR
Length1.0130
Length range1.0000+
Manufacturers catalog numberHP ADCT 2207PDR IC928
Manufacturer gradeIC928
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Material gradeC1; C2; C5; C6
Maximum depth of cut0.8900
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Relief angle15
Single or double sided insertSingle
StandardsANSI; ISO 13399
Thickness0.2950
Thickness range0.2500 to 0.3500
Width0.1010
