RCMT 1206-FW-T20 Solid Carbide Insert, Grade IC928, TiAlN - Iscar 5605469

Iscar

RCMT 1206-FW-T20 Solid Carbide Insert, Grade IC928, TiAlN - Iscar 5605469

MFR# 5605469ISO/ANSI# RCMT 1206-FW-T20Cat# RCMT 1206-FW-T20 IC928Series MILLSHRED

$19.59List $25.10 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeRound
GradeIC928
MaterialSolid Carbide
CoatingTiAlN

Description

The Iscar 5605469 is a RCMT 1206-FW-T20 solid carbide indexable insert, grade IC928, TiAlN coated. Suited for steel, stainless steel, superalloys & titanium.

Specifications

Ansi codeRCMT 1206-FW-T20 IC928
Chip breakerFW
Coating finishTiAlN
Coating processPVD
Corner radius0.2362
Cutter series compatibilityFRW; ERW
Cutting edge effective length0.4724
Cutting edge styleSegmented
Included angle degree360
Inscribed circle0.4724
Inscribed circle range0.4000 to 0.5000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRound
Insert size12
Insert size code1206
Insert styleRCMT
Iso codeRCMT 1206-FW-T20
Length0.4724
Length range0.4500 to 0.5000
Manufacturers catalog numberRCMT 1206-FW-T20 IC928
Manufacturer gradeIC928
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Maximum depth of cut0.2362
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Relief angle7
Single or double sided insertSingle
StandardsANSI; ISO 13399
Thickness0.1570
Thickness range0.1500 to 0.1750
Width0.4724
