Iscar

0.2362" 3-Flute Solid Carbide Corner Radius & Corner Chamfer End Mill, AlTiN - Iscar 5620534

MFR# 5620534Cat# ECCS060E07-3W06-57Series ECCS-E-3

$38.42List $49.20 Save 21%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Flutes3

MaterialSolid Carbide

CoatingAlTiN

Description

The Iscar 5620534 is a 0.2362 3-flute Solid Carbide (IC900) corner radius & corner chamfer end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron. Series ECCS-E-3.

Specifications

Additional informationShouldering; Slotting; Rampdown; Helical Interpolation; Drill Mill; Plunging & Recessing

CentercuttingNo

Chamfer angle45

Chamfer length (mm)0.15

Chamfer width0.0059

ChipbreakerNo

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeHelical

Helix angle38

Helix styleMedium

Length of cut0.2756

Length typeShort

Manufacturers catalog numberECCS060E07-3W06-57

Material gradeIC900

Material removal typeRoughing & Finishing

Mill diameter0.2362

Mill diameter tolerance-0.025 to 0.047

Neck diameter0.2323

Number of flutes3

Overall length (mm)57.00

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron

Reach length0.5906

Secondary workpiece materialNon-Ferrous Metal; Superalloys & Titanium; Hard Material

Shank diameter (mm)6.00

Shank diameter tolerance0.000 to -0.009 mm

Shank typeWeldon Flat

Single or double endSingle

Variable helixNo

Variable indexNo
