Carbide Insert, Grade IC908, TiAlN - Iscar 5622900

Iscar

Carbide Insert, Grade IC908, TiAlN - Iscar 5622900

MFR# 5622900Series MM EFS-CF

$144.53List $185.10 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes4
GradeIC908
CoatingTiAlN

Description

The Iscar 5622900 is a carbide indexable insert, grade IC908, TiAlN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.

Specifications

Chamfer angle45degree
ChipbreakerCommon
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Corner radius0.0000
Cutting width0.3750in
Extension from holder in0.5100
Functional length0.5100
Helix angle38
Included angle degree90
Insert handRight Hand
Insert size.375E27
Lead angle90
Length of cut0.2870in
Manufacturers catalog number5622900
Manufacturer gradeIC908
Material gradeSub Micrograin
Maximum depth of cut0.2870
Milling tip full descriptionMM EFS.375E27-4T06 CF
Milling tip styleMM EFS-CF
Milling tip typeRoughing
Number of flutes4
Overall length0.5100in
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
StandardsANSI
Tool materialCarbide
Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.

Alternate & equivalent tools

Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.

Spec-matched alternates load as the catalog fills in. Meanwhile, browse the End Mills collection and filter by diameter, flutes & length of cut.
