Carbide Insert, Grade IC908, TiAlN - Iscar 5668599

Iscar

Carbide Insert, Grade IC908, TiAlN - Iscar 5668599

MFR# 5668599Series MM FM

$101.35List $129.80 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes6
GradeIC908
CoatingTiAlN

Description

The Iscar 5668599 is a carbide indexable insert, grade IC908, TiAlN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.

Specifications

Chamfer angle0
ChipbreakerNone
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Corner radius0.0157
Cutting diameter0.7870
Cutting width0.787
Functional length0.2680
Included angle degree90
Insert handRight Hand
Insert size200-60R0.4
Lead angle90
Length of cut0.2362
Manufacturers catalog number5668599
Manufacturer gradeIC908
Material gradeSub Micrograin
Maximum depth of cut0.2362
Milling tip full descriptionMM FM200-60R0.4-06T08
Milling tip styleMM FM
Milling tip typeFace
Number of flutes6
Overall length0.268
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
StandardsANSI
Tool materialCarbide
