Carbide Insert, Grade IC908, TiAlN - Iscar 5691111

Iscar

Carbide Insert, Grade IC908, TiAlN - Iscar 5691111

MFR# 5691111Series MM ERS

$130.40List $167.00 Save 21%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes4
GradeIC908
CoatingTiAlN

Description

The Iscar 5691111 is a carbide indexable insert, grade IC908, TiAlN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.

Specifications

Chamfer angle45degree
ChipbreakerCommon
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Corner radius0.4728
Cutting diameter0.4728
Cutting width0.4728in
Extension from holder in0.6496
Functional length0.6501
Helix angle45
Included angle degree90
Insert handRight Hand
Insert size120B09
Lead angle90
Length of cut0.3546in
Manufacturers catalog number5691111
Manufacturer gradeIC908
Material gradeSub Micrograin
Maximum depth of cut0.3546
Milling tip full descriptionMM ERS120B09-4T08
Milling tip styleMM ERS
Milling tip typeRoughing
Number of flutes4
Overall length0.6501in
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
StandardsANSI
Tool materialCarbide
