Iscar
ISO 13399 Ceramic Insert, Grade IN420, TiN - Iscar 5798406
MFR# 5798406ISO/ANSI# CNGA120404Series Isoturn
$23.27List $26.60
Save 12%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeC - Diamond (Rhombic) 80-Deg
GradeIN420
MaterialCeramic
CoatingTiN
Description
The Iscar 5798406 is a ISO 13399 ceramic indexable insert, grade IN420, TiN coated. Suited for cast iron, hard material.
Specifications
Ansi insert codeCNGA431
Ansi size code431
Chip breakerT
Chip breaker operationFinishing
Clearance codeN
Coating finishTiN
Coating processPVD
Corner radius in1/64
Grade characteristicsCast Iron (K) - High Wear-Resistance; Hardened Materials (H) - High Wear-Resistance
Included angle80
Inscribed circle in1/2
Insert holding methodClamp; Pin
Insert length0.5080
Insert materialCeramic
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code431
Insert styleCNGA
Insert thickness in3/16
Iso codeISO 13399
Iso insert codeCNGA120404
Iso size code120404
Length range0.5000 - 0.6000
Manufacturer gradeIN420
Maximum depth of cut0.0157
Primary workpiece materialCast Iron; Hard Material
Relief angle0
Side clearanceNegative
StandardsISO 13399
Stocking categoryD
Tolerance codeG
