ISO 13399 Solid Carbide Insert, Grade IC908, Coated - Iscar 6095011

Iscar

ISO 13399 Solid Carbide Insert, Grade IC908, Coated - Iscar 6095011

MFR# 6095011ISO/ANSI# ISO 13399Cat# DGL 4003C-4DSeries Do-Grip

$35.28List $44.40 Save 20%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Sold in multiples of 10 — minimum order 10

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
GradeIC908
MaterialSolid Carbide
CoatingCoated

Description

The Iscar 6095011 is a ISO 13399 solid carbide indexable insert, grade IC908, Coated coated. Suited for universal.

Specifications

ChipbreakerC
Coating finishCoated
Coating processPVD
Corner radius0.0118
Cutting tool applicationParting
Cutting width0.1575
Insert handLeft Hand
Insert holding methodClamp
Insert materialSolid Carbide
Insert size code4003
Insert styleDGL
Iso codeISO 13399
Lead angle4
Lead angle directionLeft Hand
Manufacturers catalog numberDGL 4003C-4D
Manufacturer gradeIC908
Material gradeC1; C2; C6; C7
Multi use toolNo
Overall length0.7441
Primary workpiece materialUniversal
Relief angle7.00
Single or double endDouble
StandardsISO 13399
