Iscar
Single Point Threading Tools - Iscar 6402449
MFR# 6402449
$53.56List $68.60
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
CoatingTiCN
Description
The Iscar 6402449 single point threading tools.
Specifications
Coating finishTiCN
Coolant throughNo
Cutting depth0.5906
Flat width0.0350
MaterialSolid Carbide
Maximum pitch (mm)0.75
Maximum threads per inch36
Minimum pitch (mm)0.75
Minimum threads per inch24
Overall length1.1811
Profile angle60
Projection from center0.0748
Projection from edge0.0200
Shank diameter (mm)5.00
Threading diameter0.1969
Thread directionRight Hand
Thread typeInternal
