Iscar
GIMF 508 Solid Carbide Insert, Grade IC908, TiAlN - Iscar 6402802
MFR# 6402802ISO/ANSI# GIMF 508Cat# GIMF 508Series Cut Grip
$19.83List $25.40
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeIC908
MaterialSolid Carbide
CoatingTiAlN
Description
The Iscar 6402802 is a GIMF 508 solid carbide indexable insert, grade IC908, TiAlN coated. Suited for universal.
Specifications
Chip breakerF
Coating finishTiAlN
Coating processPVD
Corner radius0.0315
Cutting height0.1969
Cutting width0.1969
Full radiusNo
Insert handNeutral
Insert holding methodSelf Grip
Insert materialSolid Carbide
Insert size508
Insert size code508
Insert styleGIMF
Iso codeGIMF 508
Manufacturers catalog numberGIMF 508
Manufacturer gradeIC908
Material gradeSubmicron
Maximum depth of cut0.0047
Maximum depth of cut range0.0000 to 0.0750
Multi use toolYes
Overall length0.6024
Primary workpiece materialUniversal
RakePositive
Rake angle7.00
Single or double endSingle
StandardsISO 13399
