Ball Lock Shank, 13 mm, 4340 Steel, Black Oxide - Jergens 49656

Jergens

Ball Lock Shank, 13 mm, 4340 Steel, Black Oxide - Jergens 49656

MFR# 49656

$113.46List $113.80 Save 0%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise

Description

The Jergens 49656 is a 13 mm Ball Lock shank for the Jergens Ball Lock modular fixturing system, made from 4340 steel with a black oxide finish. It has a 22 mm head (6 mm high), a 34.6 mm shank length, a 2.5 mm key and a maximum holding force of 3.3 kN. Metric version of the 49606.

Specifications

Country of originUnited States
FinishBlack Oxide
Head diameter (mm)22.00
Head height (mm)6.00
Key size (mm)2.50
Material4340 Steel
Maximum holding force kn3.30
Shank diameter13mm
Shank diameter (mm)13.00
Shank length (mm)34.60
System compatibilityBall Lock
