Kennametal
Indexable Threading Toolholders - Kennametal 1097247
MFR# 1097247Series Top Notch
$152.21List $182.57
Save 16%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Kennametal 1097247 indexable threading toolholders. Series Top Notch.
Specifications
Back of bar to cutting edge0.7500
Coolant throughNo
Cutting tool applicationGrooving; Threading
Hand of holderLeft Hand
Head length0.5000
Insert compatibilityN.2R
Insert holding methodClamp
Maximum depth of cut0.1380
Multi use toolYes
Overall length in3-1/2
Shank height in1/2
Shank width diameter in1/2
Thread typeInternal & External
Toolholder styleNE
