C - Diamond (Rhombic) 80-Deg 3/4" IC Carbide Insert, Grade K68 - Kennametal 1161157

Kennametal

C - Diamond (Rhombic) 80-Deg 3/4" IC Carbide Insert, Grade K68 - Kennametal 1161157

MFR# 1161157ISO/ANSI# CNMS190608Series KENLOC

$45.06List $55.00 Save 18%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/4
ShapeC - Diamond (Rhombic) 80-Deg
GradeK68
MaterialCarbide

Description

The Kennametal 1161157 is a carbide indexable insert, grade K68. Suited for non-ferrous metal, superalloys & titanium.

Specifications

Ansi insert codeCNMS642
Ansi size code642
Chip breakerCommon
Chip breaker operationMedium Machining
Clearance codeN
Coating processUncoated
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Grade characteristicsStainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Cast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness; Aluminum & Non-Ferrous (N) - High Wear-Resistance to Moderate Wear-Resistance and Toughne
Hole diameter0.3125
Included angle80
Industry standard numberCNMS642
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.7616
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code642
Insert styleCNMS
Insert thickness in1/4
Iso insert codeCNMS190608
Iso size code190608
Length range0.7000 - 10.0000
Manufacturers catalog number1161157
Manufacturer gradeK68
Material gradeC3
Maximum depth of cut0.0492
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialNon-Ferrous Metal; Superalloys & Titanium
RakeNegative
Rake angle20
Relief angle0
Side clearanceNegative
StandardsANSI; ISO
Tolerance codeM
Width in3/4
Wiper edgeNo
