Kennametal
XPMT150412L Solid Carbide Insert, Grade KC725M, TiN - Kennametal 1181487
MFR# 1181487ISO/ANSI# XPMT150412LCat# XPMT150412LSeries XPMT
$41.10List $50.17
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeParallelogram
GradeKC725M
MaterialSolid Carbide
CoatingTiN
Description
The Kennametal 1181487 is a XPMT150412L solid carbide indexable insert, grade KC725M, TiN coated. Suited for steel, stainless steel, superalloys & titanium.
Specifications
Coating finishTiN
Coating processPVD
Corner radius in3/64
Hole diameter0.2165
Included angle degree88
Inscribed circle in3/8
Insert handLeft Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeParallelogram
Insert size15
Insert size code150412
Insert styleXPMT
Iso codeXPMT150412L
Length0.6394
Length range0.6000 to 0.6500
Manufacturers catalog numberXPMT150412L
Manufacturer gradeKC725M
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Material gradeC5; C6; C7
Maximum depth of cut0.3750
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
Relief angle11.00
Single or double sided insertSingle
Thickness in3/16
Thickness range0.1850 to 0.2000
Width in1/2
