D - Diamond (Rhombic) 55-Deg 1/2" IC Carbide Insert, Grade KC7310, TiAlN - Kennametal 1310923

Kennametal

D - Diamond (Rhombic) 55-Deg 1/2" IC Carbide Insert, Grade KC7310, TiAlN - Kennametal 1310923

MFR# 1310923ISO/ANSI# DNGP150404Series KENLOC

$42.96List $52.44 Save 18%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeD - Diamond (Rhombic) 55-Deg
GradeKC7310
MaterialCarbide
CoatingTiAlN

Description

The Kennametal 1310923 is a carbide indexable insert, grade KC7310, TiAlN coated.

Specifications

Ansi insert codeDNGP431
Ansi size code431
Chip breakerP
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius in1/64
Hole diameter0.2031
Included angle55
Industry standard numberC2FIX180610LMN
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.6102
Insert materialCarbide
Insert shapeD - Diamond (Rhombic) 55-Deg
Insert size code431
Insert styleDNGP
Insert thickness in3/16
Iso insert codeDNGP150404
Iso size code150404
Length range0.6000 - 0.6500
Manufacturers catalog number1310923
Manufacturer gradeKC7310
Material gradeC3; C4
Maximum depth of cut0.0492
RakeNegative
Relief angle0
Side clearanceNegative
Tolerance codeG
